ISO9809-1
34CrMo4
116mm
3L-5L
166.7-174bar
250bar
Concave/convex
PED/TPED
| Quantity: | |
|---|---|
| Serial number | Type | Outside diameter(mm) | Working pressure (Bar) | Test pressure (Bar) | Material | Design wall thickness(mm) | Water Capacity(L) | Height (mm) | Weight (kg) | Certificate |
| 11 | 116-3.0-250 | 116 | 174（PED）166.5（TPED） | 250 | 34CrMo4 | 2.18 | 3.0 | 380 | 3.9 | PED TPED |
| 116-5.0-250 | 116 | 174（PED）166.4（TPED） | 250 | 34CrMo4 | 2.18 | 5.0 | 600 | 5.6 | PED TPED | |
| 116-7.5-250 | 116 | 174（PED）166.3（TPED） | 250 | 34CrMo4 | 2.18 | 7.5 | 860 | 7.6 | PED TPED |
Material 34CrMo4 has stronger tensile strength and yield strength, blasting pressure is greater than 400bar. Alloy steel cylinder is more ligher weight than 37Mn and carton steel.
| Serial number | Type | Outside diameter(mm) | Working pressure (Bar) | Test pressure (Bar) | Material | Design wall thickness(mm) | Water Capacity(L) | Height (mm) | Weight (kg) | Certificate |
| 11 | 116-3.0-250 | 116 | 174（PED）166.5（TPED） | 250 | 34CrMo4 | 2.18 | 3.0 | 380 | 3.9 | PED TPED |
| 116-5.0-250 | 116 | 174（PED）166.4（TPED） | 250 | 34CrMo4 | 2.18 | 5.0 | 600 | 5.6 | PED TPED | |
| 116-7.5-250 | 116 | 174（PED）166.3（TPED） | 250 | 34CrMo4 | 2.18 | 7.5 | 860 | 7.6 | PED TPED |
Material 34CrMo4 has stronger tensile strength and yield strength, blasting pressure is greater than 400bar. Alloy steel cylinder is more ligher weight than 37Mn and carton steel.
