ISO9809-1
34CrMo4
154mm
5L-10L
166.7-174bar
250bar
Concave/convex
PED/TPED
| Quantity: | |
|---|---|
| Type | Outside diameter(mm) | Working pressure (Bar) | Test pressure (Bar) | Material | Design wall thickness(mm) | Water Capacity(L) | Height (mm) | Weight (kg) | Certificate |
| 154-4.5-250 | 154 | 174（PED）166.7（TPED） | 250 | 34CrMo4 | 2.89 | 4.5 | 350 | 5.9 | PED TPED |
| 154-7.5-250 | 154 | 174（PED）166.7（TPED） | 250 | 34CrMo4 | 2.89 | 7.5 | 530 | 8.1 | PED TPED |
| 154-10.0-250 | 154 | 174（PED）166.7（TPED） | 250 | 34CrMo4 | 2.89 | 10.0 | 675 | 9.9 | PED TPED |
| 154-15.0-250 | 154 | 174（PED）166.7（TPED） | 250 | 34CrMo4 | 2.89 | 15.0 | 970 | 13.5 | PED TPED |
Material 34CrMo4 has stronger tensile strength and yield strength, blasting pressure is greater than 400bar. Alloy steel cylinder is more ligher weight than 37Mn and carton steel.
| Type | Outside diameter(mm) | Working pressure (Bar) | Test pressure (Bar) | Material | Design wall thickness(mm) | Water Capacity(L) | Height (mm) | Weight (kg) | Certificate |
| 154-4.5-250 | 154 | 174（PED）166.7（TPED） | 250 | 34CrMo4 | 2.89 | 4.5 | 350 | 5.9 | PED TPED |
| 154-7.5-250 | 154 | 174（PED）166.7（TPED） | 250 | 34CrMo4 | 2.89 | 7.5 | 530 | 8.1 | PED TPED |
| 154-10.0-250 | 154 | 174（PED）166.7（TPED） | 250 | 34CrMo4 | 2.89 | 10.0 | 675 | 9.9 | PED TPED |
| 154-15.0-250 | 154 | 174（PED）166.7（TPED） | 250 | 34CrMo4 | 2.89 | 15.0 | 970 | 13.5 | PED TPED |
Material 34CrMo4 has stronger tensile strength and yield strength, blasting pressure is greater than 400bar. Alloy steel cylinder is more ligher weight than 37Mn and carton steel.
